                                        Log splitter Cylinders
    Replacement Hydraulic cylinders  for All Types of log splitters starting price of $ 159.95



 Low Dollar Deals on Hard to find Log Splitter Cylinders for Yard Machine , MTD, Troy Built, Speedco, Duerr, White, DR,  IMS, Tractor Supply Huskey, Rayco, Timber Wolf, Iron Oak and other brands.

1





  • 4" Bore x 24" Stroke x 1.750" Shaft
  • Pin 1.250" Base End Weled on
  • 1/2" Pin on shaft End of Cylinder
  • Retract  32.5" Pin to Pin Center
  • Extended 56.5"
  • SAE Port Size N0. 8

Part No.  EZ 4024 LS -1.75   $ 250.00

Shipping Weight 61 Lbs.




2









  • 4 1/2" Bore x 24" stroke x 1.750" shaft
  • Pin 1.250" Base End Weled on
  • 1/2" Pin on shaft End of Cylinder
  • Retract 32.5"
  • Extended 56.5"
  • Sae Port size N0. 8

Part No.  EZ 4524LS -1.75     $ 287.00

Shipping Weight  70 Lbs


3








  • 5" Bore x 24" stroke x  2" shaft
  • Clevis Pin 1.250" Base End Weled on
  • 1/2" Pin on shaft End of Cylinder
  • Retract 32.5"
  • Extended 56.5"
  • SAE No. 8 Port Size

Part No.  EZ 5024LS-2   $ 377.00

Shipping Weight 83 Lbs



4

Hydraulic cylinders for Log Splitters

4" Bore  x 24" Stroke 2" SHAFT 3000 PSI = EZ 4024 CW  $ 179.95

wood log splitter hydraulic cylinders




Bore Stroke Closed Pin Center Distance Shaft Diameter Port Size  Clevis Pin Diameter Weight (lbs)
Retracted Extended
4" 24" 34.25" 58.25" 2" SAE 8 1" 71



5



4"  Bore 24" Stroke 2" shaft Pin size 1.500" on cross tube 3000 PSI

   EZ 4024 BW   $ 178.00









3000 psi Hydraulic cylinders sold by Splitez import cross tube














1- 661 - 248 - 5270                     Phone

6

Hydraulic Cylinders Maxim 3000 PSI Welded Series

  4" Bore x 24" Stroke x 2" Shaft 3000 PSI Shaft Welded Cylinder Clevis ends

Part NO.  EZ Max 4242   Price $ 250.95     61#

Bore Stroke Closed Pin Center Distance Shaft Diameter Port Size  Clevis Pin Diameter Weight (lbs)
Retracted Extended
4" 24" 34.25" 58.25" 2" SAE 8 1" 71

7

Hydraulic Cylinders Maxim 3000 PSI Welded Series

4" x 30" x 2"  EZ MAX  4302  Price  $ 280.00







 1-661-248-5270                     Phone

8



4x24 x2 inch shaft 3000 psi cylinder

  Pin size 1" - 3000 psi welded    20 Ton  4" x 24" x 2" Shaft

NO.286-065

EZ-1065   SALE  PRICE         $ 325.00

   Ship Wt  61 Lbs.



Bore Stroke Closed Pin Center Distance Shaft Diameter Port Size  Weight (lbs)
Retracted Extended
4" 24" 34.25" 58.25" 2" SAE 8#


61




 4 x 24 x 24"x 24" x 2" Shaft  20 Ton

 Pin Size 1" - 3000 PSI Tie Rod

NO.214-428

EZ-1405    Sale  Price     $ 285.00

   Ship Wt. 79 Lbs.



Bore Stroke Closed Pin Center Distance Shaft Diameter Port Size  Weight (lbs)
Retracted Extended
4" 24" 34.25" 58.25" 2" SAE 8#



79


10

 5 x 24 x 2.250 Shaft Tie rod   cylinder 3000 psi



BIG SHAFT 24" STROKE

  Pin Size 1 1/4 " 3000 psi Tie Rod        30 Ton      5"x 24" x  2.250" Shaft

 NO.214-428

 EZ-1428    Sale Price       $ 419.00

      Ship Wt 127 Lbs.



Bore Stroke Closed Pin Center Distance Shaft Diameter Port Size  Weight (lbs)
Retracted Extended
5" 24" 36.25" 60.25" 2.250" SAE 12#


127




11

 5 x 24 x 2.250 Tie rod hydraulic  cylinder 3000 psi



BIG SHAFT 30" STROKE

  Pin Size 1 1/4 " 3000 psi Tie Rod        30 Ton      5"x 30" x  2.250" Shaft

 NO.214-430

 EZ-1430    Sale Price       $ 455.00

      Ship Wt 145 Lbs.



Bore Stroke Closed Pin Center Distance Shaft Diameter Port Size  Weight (lbs)
Retracted Extended
5" 24" 42.25" 72.25" 2.250" SAE 12#


145





 1-661-248-5270                     Phone






12

Hydraulic cylinder wood splitter 5" x 24" 2" shaftMade in the USA



  MFG. Part No. B500240ACDDAO7B

         PMC- 50242  Cylinder  3000 Psi

Our price $ 425.00   5" x 24" X 2" Shaft  Prince Tie Rod

Bore Stroke Closed Pin Center Distance Shaft Diameter Port Size  Weight (lbs)
Retracted Extended
5" 24" 36.25" 60.25" 2" SAE 10#


113








13

5" Bore x 30" Stroke  x  2"  Shaft  $ 465.00 Prince U.S.A

Hydraulic cylinder wood splitter 5" x 30"  x 2" shaftMade in the USA



  MFG. Part No. B500300ACDDAO7B

         PMC- 50302  Cylinder  3000 Psi  Painted Yellow

Our price $ 475.00   5" x 30" X 2" Shaft  Prince Tie Rod

Bore Stroke Closed Pin Center Distance Shaft Diameter Port Size  Weight (lbs)
Retracted Extended
5" 30" 42.25" 72.25" 2" SAE 10#


129






14

  • wood splitter hydraul;ic cylinder splitez Made in the USA





       PMC 21024  Prince  Gladiator cross tube 3000 psi Hydraulic Cylinder  1-1/2"  pin holes

Our Price  $ 599.00    5" Bore 24" Stroke 2 1/2" Shaft



8 or more call

Bore Stroke Closed Pin Center Distance Shaft Diameter Port Size  Weight (lbs)
Retracted Extended
5" 24" 35" 59" 2.500" NPTF 3/4"


115






15



  • Splitez log splitter cylinder Made in the USA






 PMC 21030 Prince Gladiator cross tube Hydraulic Cylinder 3000  psi



Our Price  $ 650.00    5" Bore 30" Stroke 2 1/2" Shaft



Bore Stroke Closed Pin Center Distance Shaft Diameter Port Size  Weight (lbs)
Retracted Extended
5" 30" 41" 71" 2.500" 3/4" NTPF


130






16

  • Log wood splitter cylinder  %" bore 36" stroke 2.5 shaft Gladiator Made in the USA






  PMC 21036  Prince Hydraulic Cylinder Gadiator cross tube 3000 psi

 Now  $ 699.00    5" Bore 36" Stroke  2 1/2" Shaft



Bore Stroke Closed Pin Center Distance Shaft Diameter Port Size  Weight (lbs)
Retracted Extended
5" 36" 47" 83" 2.500" 3/4" NPTF


145




17

  • Prince gladiator 6 " x 24 x 3" shaft  log splitter cylinder Made in the USA






  PMC 22024  Prince Gladiator Hydraulic Cylinder Cross Tube 3000 psi

 Now  $ 750.00    Bore 6" Stroke 24"  Shaft 3"

8 or more only  Call



Bore Stroke Closed Pin Center Distance Shaft Diameter Port Size  Weight (lbs)
Retracted Extended
6" 24" 35" 59" 3" 3/4"  NTPF


150




18

3000 psi weled hydraulic cylinder 3.5 X 24 X
1.750 shaft



  3.5 Bore x 24 Stroke x 1.75 3000 PSI Shaft Welded Cylinder   EZ 3524 CW    $ 145.00


19

300 psi hydraulic cylinder  log splitter 2

2500 psi Tie Rod       4"X 24"X 2" Shaft

EZ-4024 T-2            Price   $ 149.00



Bore Stroke Closed Pin Center Distance Shaft Diameter Port Size  Clevis Pin Diameter Weight (lbs)
Retracted Extended
4" 24" 34.25" 58.25" 2" 1/2" NPTF 1" 70
