Hydraulic oil reservoirs

Hydraulic Reservoirs Oil Tanks With Integral Mounting Brackets & Parts to Build Your Own

1-661-248-5270 Phone

Features
10 and 12 Gauge steel construction reservoir
3/4" screen in breather cap
3/4" magnetic drain plug
1-1/4" suction ports
1" return ports
Factory powder coated

Multiple Mounting Positions for reservoirs

Low profile design allows for use in small areas
All sides of the reservoir are ported, allowing for multiple position mounting

7-Gallon Steel Reservoir with Integral Brackets - Buyers SMR7S

Can be shipped U.P.S.

Click here for detail drawing of tank

Part Number	Description	Usable Capacity	Weight	Price
SMR7S	7 Gallon Tank Hydraulic Oil Reservoirs	7.0 Gallons	35 Lbs	$ 175.00

SMR7S 8 or more $ 135.00 each

Features
13 gauge H.R.P.O. steel
Welded mounting angles
1/4 turn chrome filler breather w/basket strainer
Oil level gauge with temperature indicator
Interior baffle between suction and discharge
Large 2" NPT suction ports
Magnetic drain plug
Factory powder coated
Fully tested

Reservoirs Oil Tanks Can be shipped U.P.S.

SMR15S

CAN BE SHIPPED U.P.S

Click here for detail drawing of tank

Part Number	Description	Usable Capacity oil	Weight	Price
SMR 15S	15 Gallon Hydraulic Tank Reservoirs	11.0 Gallon	53 Lbs.	$ 210.00

SMR 15S 8 or more $ 175.00 each

Features

• 13 Gauge H.R.P.O. steel

• Welded mounting angles

• 1/4 turn chrome filler breather w/basket strainer

• Oil level gauge with temperature indicator

• Interior baffle between suction and discharge

• Large 2" NPT suction ports

• Magnetic drain plug

• Factory powder coated

• Fully tested

• Can be shipped U.P.S.

Click here for detail drawing of tank

Part Number	Description	Usable Capacity Hydraulic Oil	Weight	Price
SMR25S	25 Gallon Tank	18.0 Gallon	71 Lbs	$ 225.98

SMR25S 8 or more $ 209.00 each

Features
13 Gauge H.R.P.O. steel
Welded mounting angles
1/4 turn chrome filler breather w/basket strainer
Oil level gauge with temperature indicator
Interior baffle between suction and discharge
Large 2" NPT suction ports
Magnetic drain plug
Factory painted or primed
Fully tested
Top drain port
Port to accommodate breather monitor kit (in cab warning light
kit) VSK05
Port to accommodate fluid level gauge (light-indicator in cab)

Can be shipped U.P.S.

Click here for detail drawing of tank

Part Number	Description	Usable Capacity Oil	Weight	Price
SMR30S	30 Gallon Reservoir Tank	30.0 Gallon	84 lbs.	$ 299.00

SMR30S 8 or more $ 239.79 each

Features
12 gauge H.R.P.O. steel
Welded mounting angles
1/4 turn chrome filler breather w/wire basket strainer
Site level gauge
Interior baffle between suction and discharge
Large 2" NPT suction port 1-1/4" NPT return
Magnetic drain plug with sump
Painted flat black
Fully tested
3/4" NPT load sensing pump drain port
Clean out cover standard
Accepts tank mounted return filter
Accepts tank mounted suction strainers

SHIPPED BY FREIGHT

Click here for detail drawing of tank

Part Number	Description Of Tank	Usable Capacity Oil	Weight	Price
SMR37S	37 Gallon Reservoir	37.0 Gallon	103 lbs	$335.00

SMR37S 8 or more $ 293.36 each

1-661-248-5270 Phone

FRAME MOUNT TANK STEEL

HD 7/11 Gage steel construction
Black power cated finish
Mounts between fram rails, behind cab or
8 Gallon Tank fully baffled
Hydraulic valve cable or air operated for dump valve operated
Compack low - profile design

PART No.	DESCRIPTION	USABLE CAPACITY	WEIGHT	PRICE
FMR8S	8 Gallon Frame Mount Steel Reservoir No Valve		60.50 Lbs.	$ 222.95
FMRS3W	8 Gall Steel Tank, Power up / Gravity Down		73.58 Lbs.	$ 325.95
FMR8S3WPB	8 Gall Power up / Gravity Down - Power Beyond*		74.50 Lbs.	$ 346.95
FMR8S4W	8 Gall Steel Tank Power up / Power Down		75.75 Lbs	$ 369.95
FMR8S4WPB	8 Gall Power Up / Power Down -Power Beyond*		75.54 Lbs	$ 339.95

When Ordeing Air or Cable Operated Valve

* Indicates Power Beyond Valve

50 & 70 Gallon Steel

• Sturdy 12 gauge steel construction

• Fully baffled

• Includes a 1/4 turn filler breather unit and

domed vent

• Includes hardware mounting kit, sight temp.,

level gauge.

More Info Click Here

PART No.	DESCRIPTION	USABLE CAPACITY	SHIPPING WEIGHT	PRICE
UR50S	50 Gallon Steel	50.0 Gallons	157.00 Lbs.	$ 396.00
UR70S	70 Gallon Steel	67.5 Gallons	206.00	$ 498.00

UPRIGHT ALUMINUM 50 & 70 Gallon

• High-quality bright tread aluminum construction
• Includes filler-strainer breather cap assy., plus second breather cap, & oil level sight gauge w/temp. indicator
• Full internal baffle
• Includes hardware mounting kit
• Individually boxed

More Infomation Click Here

PART No.	DESCRIPTION	USABLE CAPACITY	WEIGHT	PRICE
UR50A	50 Gallon Aluminum	50.0 Gallon	58 Lbs.	$ 498.00
UR70A	70 Gallon Aluminum	67.5 Gallon	73 Lbs	$ 598.00

35 - 50 & 70 GALLON SIDE MOUNT ALUMINUM

PART NO.	DESCRIPTION	USABLE CAPACITY	WEIGHT	PRICE
SMC35A	35 Gallon Side Mount Aluminum		74.00 Lbs	$ 449.00
SMC50A	50 Gallon Side Mount Aluminum		77.00 Lbs	$ 499.95
SMC70A	70 Gallon Side Mount Aluminum		83.50 Lbs	$ 659.00
